Stubbe vertical pump

Stubbe Vertical Oump - ETLB-S

  • vertical single-stage immersion pump in block design
  • equipped with a freewheeling shaft for protection against dry running
  • broad range of applications through diverse construction and material combinations
  • excellent operating reliability even under extreme operating conditions
  • high availability due to simple modular design in the immersion depths 275/295, 375/395, 475/495
  • special mounting plate and connection designs available on request
  • equipped with a freewheeling shaft for protection against dry running
  • Impeller fastened on the motor shaft independent of the rotational direction
  • Screwless plastic spiral housing made of PP or PVDF
  • Three-phase motor manufactured by STUBBE
  • Corrosion protection through 2-component protective paint

Ritmo Electrofusion Machine

Ritmo universal electrofusion machine, suitable for welding pipe/fittings for the transport of gas, water and for welding fire sprinkler system (HDPE, PP, PP-R couplings from 8 to 48 V). The Elektra Light machine is made in compliance with international standards. This is welding machine’s structure is light weight, so it is extremely easy to carry around. Composed of: machine body, an in built memory with 325 welding cycles, featuring the possibility of transferring data to a Pc/Laptop, report in PDF file

Ritmo delta 1600 Butt Fusion for Pressure Pipe

This is a self-aligning welding machine with hydraulic clamps suitable for welding HDPE pipes for the transport of water and other fluids under pressure, up to Ø 1600 mm. The DELTA 1600 HDR is designed in accordance to International standards (UNI 10565, ISO 12176-1). The DELTA 1600 HDR can weld fittings such as elbows, tees, branches and flange necks. Robust machine body made of steel and hydraulic clamping, able to automatic detaching device of heating plate.

Ritmo Butt Welding Machine

With RITMO EASY LIFE it is possible to Butt weld fittings such as elbows, tees, wyes and stub ends. This is possible because the 3rd clamp can be anchored to the 1st and 2nd (movable) and slide along with the pipe. The fitting have to be locked in the 4th clamp. Short neck stub ends can be welded with the help of a special tool (on request).

Thanks to a special gearcase  the EASY LIFE is able to manage the welding process in a semi-automatic way from OD 40 to 630 mm.

The electronic system guarantees the continuous repeat of the welding cycles and automatic control of the preset parameters, therefore the operator needs only to validate the welding phases. The user-friendly graphic display allows a quick setting of the desired parameters.

The EASY LIFE system can store up to 4000 welding cycles and sum them up into a PDF file. This report can be transferred to a PC/laptop through a USB port.
Possibility to pre-set 50 customized.
The EASY LIFE system data-logging now shows the time!
